sensor gerak kendaraan untuk sistem kontrol lampu jalan cerdas

sesuai dengan lingkungan jalan/terowongan, bekerja sama dengan pengontrol terpusat pencahayaan cerdas untuk secara otomatis mengontrol pencahayaan lampu sesuai dengan perubahan kecerahan lingkungan, untuk mencapai tujuan manajemen dan kontrol cerdas.

According to the real time traffic flow rate conditions, it cooperates with the intelligent lighting centralized controller to automatically control the illuminance of the roadway lights according to the changing of city roads brightness, to achieve the purpose of intelligent public lighting management.

Key Features n Applicable to signal control systems, traffic information service systems, road traffic monitoring and other application scenarios. n High precision millimeter wave radar with 4 million low illumination camera. n Max. 8 lanes of multi-target motor vehicles detection, longitudinal distance of 100m. n High spatial resolution and strong penetration ability, support working in all-weather environment, not affected by rain, fog, strong wind, dust, light, etc. n Built-in deep learning algorithm, support intelligent recognition function, support license plate recognition and target fully structured. n Supports detection of multiple targets’ position, lane, speed, direction and other info. n It supports lane statistics, traffic flow, speed, status, queue, time distance, spacing, Qty.of parking areas, avg.delay, space occupancy and time occupancy data, and supports statistical upload from 1 to 3600 seconds. n Supports traffic evaluation data output, including congestion, queue length, etc. n Each lane supports 2 virtual coils to output vehicle entry and exit signals, the virtual coil positions are configurable. n Fog penetration, strong light suppression, wide dynamic range, and has multiple white balance modes to suit various scene requirements. n Support Network & RS-485 data upload. Parameters Millimeter Wave Radar Target Type People / Motor Vehicles / Non-Motor Vehicles Max. Qty. of Detection 128 Working Frequency 80 ~ 81GHz Transmit power 12dBm(RFout)+18dB(ANTgain) Speed Detect Range -250 km/h ~ 250 km/h Detection Mode Doppler moving target detection, slow moving target detection, fast moving target detection Sweep bandwidth 136.5 MHz Modulation Waveform FMCW Max. Detection Distance 150m@0° ;    50m@士45° Horizontal angle measurement range 士45° Horizontal lobe 90° for MRR, 22° for  LRR Vertical Lobe 13°(-6dB) Refresh rate 12.5Hz Install Height 1~ 6m   Interface Serial Port 1 of RS-485 Port Snapshot Function Image Format JPEG Image resolution 2688 × 1520 Smart Functions Intelligent recognition Bayonet capture, license plate recognition, vehicle model recognition, vehicle body color recognition, brand, sub-brand. Exterior Interface Ethernet 2pcs RJ45 100 M / 1000 M Adaptive Ethernet port  Warning 1 Relay switch Function Features Min.illumination Colorful: 0.01 Lux @ (F1.2，AGC ON) Black & White: 0.001 Lux @ (F1.2，AGC ON) shutter 1/25s ~ 1/100,000s Video compression standards H.264, H.265, MJPEG Compression output bit rate 32 Kbps ~ 16 Mbps Video resolution 2688 × 1520 Frame rate 25 fps (2688 × 1520) Image Settings Saturation, brightness, contrast, white balance, gain adjustable through software Storage function TF General functions Heartbeat, password protection, NTP time synchronization Video format PAL General Specifications Dimmensions 226 mm (W) x 375.3 mm (H) x 206.4 mm (D) Working Temperature -30 °C ~ +70 °C Working Humidity 5% ~ 95% @ 40 °C，No condensation Working Voltage DC 24 V ± 10% Power Consumption 25 W Max. N.W. 3 kg ICR Type Infrared IP Rating IP67 Focal Length 12 mm Resolution 2688 × 1520 White Balance Automatic white balance Wide dynamic range Support Max. Energy Optimization achieving by the Smart Traffic Radar  and Video all-in-one Detecting Machine

fitur utama: 1. cetakan profil aluminium die-casting dan ekstrusi untuk tampilan jalur perakitan modern. 2. dua warna antara desain putih dingin dan putih hangat/putih alami untuk memenuhi kondisi cuaca tidak normal: area bersalju lebat, kabut serios & hujan , secara otomatis mengubah CCT dari 4500K/6000K menjadi 2700K ...... oleh sensor cerdas saat mendeteksi kabut tebal, hujan badai atau turun salju. 3. sistem penerangan jalan cerdas adalah elemen inti untuk platform kota pintar, 4. 80% dari penghematan daya maksimum. daripada lampu natrium tekanan tinggi tradisional

ituCH-L 0101 loop controller dikembangkan secara independen oleh perusahaan kami. ditujukan untuk penerangan industri untuk gudang dan pabrik, bangunan , stasiun , dan sistem kontrol pencahayaan terowongan pintar , dll . , untuk mengontrol catu daya perlengkapan pencahayaan melalui antarmuka manusia-mesin , untuk mengumpulkan data dan memantau status loop catu daya. yang paling diuntungkan untuk sistem peredupan loop adalah menghemat banyak pengontrol lampu individu pada setiap perlengkapan pencahayaan, cukup sesuaikan semua lampu' kecerahan dengan kotak catu daya pengontrol terpusat, kabin distribusi juga dapat dihubungkan dengan sensor gerak atau sensor penerangan untuk menjamin manajemen penghematan daya yang paling efektif.

server, workstation, kontrol layar sentuh di tempat, seluler (ipad) dan perangkat genggam lainnya, pengontrol terpusat yang cerdas (atau gateway), pengontrol sakelar loop, pengontrol peredupan loop, tunggal- terminal manajemen pencahayaan cerdas lampu, terminal manajemen pencahayaan cerdas lampu ganda, dua warna (2700k~6000k)terminal manajemen pencahayaan cerdas, dual-mode (hibrida plc+lora)terminal manajemen pencahayaan cerdas, terminal manajemen pencahayaan cerdas multi-fungsional, sakelar panel pintar, pengukur penerangan (atau pengukur kecerahan), sensor gerak, sensor penghubung, sensor gas, sensor cuaca, dll., dan peralatan profesional darurat atau pendukung (repeater, pengontrol salinan, monitor, peralatan debugging, dll.).

Why Choose an IoT-Enabled Hybrid Solar + Grid Street Lighting System? Modern cities are experiencing rapid expansion, rising energy demand, and an increasing need for reliable public infrastructure. Street lighting is one of the largest electricity consumers in any municipality, and traditional grid-powered lighting systems often struggle with high operating costs, unstable power supply, and limited management capability. At the same time, purely solar street lights face their own challenges, such as insufficient sunlight during rainy or cloudy seasons, battery degradation, and inconsistent performance in regions with harsh climates. These issues have created a strong global demand for a more resilient, intelligent, and cost-effective lighting solution—leading to the rise of IoT-enabled hybrid solar + grid street lighting systems. A hybrid street lighting system integrates three essential components: solar energy, the local electrical grid, and a high-cycle LiFePO4 battery backup. During sunny days, the solar panel provides power and charges the battery. At night or during cloudy periods, the system intelligently switches to battery or low-tariff grid electricity depending on availability. This dual-source architecture solves the “solar only” reliability problem while significantly reducing dependence on expensive peak-hour grid electricity. Cities benefit from lower electricity bills, improved lighting reliability, and reduced CO₂ emissions without compromising performance. The addition of IoT technology further transforms the system from a basic lighting device into a smart, data-driven infrastructure asset. With IoT lamp-level controllers, each street light can report real-time information such as voltage, current, temperature, battery state of charge, and power consumption. Faults—such as LED failure, low battery, or power loss—are automatically detected and sent to a centralized monitoring platform. This enables cities to replace traditional manual inspection with predictive maintenance, reducing manpower costs and minimizing downtime. IoT also enables precise lighting control. Municipalities can schedule automatic ON/OFF times, dim lights during low-traffic hours, or adjust brightness in response to weather, road conditions, or special events. When applied across thousands of street lights, these small adjustments can reduce energy consumption by 30% to 70%. Combined with hybrid power, cities can ensure that every roadway, rural village, industrial zone, or highway retains stable lighting even during extended rainy seasons, power outages, or natural disasters. For developing countries or regions with unstable grids, hybrid solar + grid IoT street lights offer an especially powerful advantage: continuous lighting security. Frequent blackouts are no longer a threat, and the system can maintain illumination for several nights using battery backup alone. This significantly improves road safety, reduces crime risk, and supports 24-hour economic ...

pengontrol loop terpusat CH-J106 dikembangkan secara independen oleh perusahaan kami. ditujukan untuk jalan raya, terowongan,penerangan industri untuk gudang dan pabrik,bangunan dan stasiun, dll., untuk mengontrol catu daya pencahayaan perlengkapan melalui antarmuka manusia-mesin, untuk mengumpulkan data dan memantau status perlengkapan pencahayaan.
